Project Description
Quiet 1hp Induction motor;
Tough powder coated paint finish;
Quick action metal bag clamps;
- Cabinet mounted trunion system: the precision-machined cast iron trunions are mounted to the cabinet to ensure perfect blade alignment, increased stability and to eliminate vibration;
- New riving knife:quick release riving knife with 2 tightenning knobs gives users easiness in setup/remove the blade guards and splitters. Easy to adjust high/low profile for the riving knife can be done from the table top;
- Magnetic table insert at slot’s end: provide users in removing easily from the table top in seconds;
Model | W1-TSC10B W1-TSC10BG(granite) |
Motor | 1-3/4HP TEFC,120V/240V,15/7.5A |
Switch | Paddle type |
Speed | 3450rpm |
Blade size | 10″×5/8″ |
Max cutting height | 3-3/8″(90°)/2-1/4″(45°) |
Rip right of blade | 36″ |
Rip left of blade | 20″ |
Table in front of blade | 12-1/2″ |
Dado capacity | 13/16″ |
Table size | 27″×62″ |
Table material | Cast iron or Granite |
Dimentsions | 72″L×31″W×35″H |
Weight | 414.5lbs |
